AFIP Wednesday Slide Conference - No. 10
3 December 1997

Conference Moderator: Michael A. Eckhaus
NCRR LSS SSB, Bldg. 28A, Rm 117
28 Library Drive, MSC 5210
Bethesda, MD 20892-5210

Return to WSC Case Menu.

Case I - RB97-2341 (AFIP 2593330)

Signalment: Adult, female, pregnant rabbit.

History: This doe was part of an atherosclerosis study involving embryo transfer. This naturally impregnated doe was due to deliver on 4/07/97. She delivered one underdeveloped stillborn kit on 4/03/97 but failed to expel the others. She was lethargic and depressed and continued to be so on 4/04/97. The animal was euthanized and submitted for necropsy.

Gross Pathology: The pubic symphysis was partially dilated, and a serosanguineous discharge was present within the vaginal canal. Both uterine horns were distended, with the right horn containing three partially macerated fetuses and the left horn containing two fetuses in similar stages of degeneration. The uterine wall was extremely friable and hemorrhagic, with fibrin strands on the serosal surface of the uterus. A total of seven placentas was noted, with four present on the right side and three on the left side. Both the placentas and the wall of the uterus appeared necrotic. Mild atherosclerosis was present involving the proximal aorta. The heart appeared grossly normal. The lungs were diffusely moderately congested. The liver was yellowish-brown with increased friability, consistent with lipidosis. The kidneys, spleen, pancreas, and GI tract appeared normal, with a moderate amount of ingesta present in the stomach.

Laboratory Results: Bacterial cultures were obtained from the surface and lumen of the uterus. Staphylococcus aureus was cultured from an intrauterine site.

Contributor's Diagnosis and Comments: Uterus: endometritis, necrotizing, Staphylococcus aureus, diffuse, severe, acute. Placenta: ischemic necrosis, diffuse. Fetuses: maceration.

Etiology: Staphylococcus aureus

This rabbit had severe necrotizing metritis due to bacterial infection of the uterus with Staphylococcus aureus. Numerous bacterial colonies consistent with Staph. were present in the affected uterine mucosa, and culture of the uterus yielded pure growth of Staphylococcus aureus.

Staphylococcosis is characterized by fatal septicemia or suppurative inflammation in an organ or body site caused by Staphylococcus aureus and is a common disease in both domestic and wild rabbits. The disease is usually sporadic and of little economic importance for commercial rabbitries. Most often, suppurative lesions are seen with staphylococcal infections, often leading to chronic abscessation in affected sites. The acute, septicemic form occurs mostly in neonatal kits and can have lesions ranging from few and nonspecific to multifocal and suppurative in various organs, including the lung, kidney, spleen, heart, and liver.

Metritis and fetal death associated with staphylococcal infection in rabbits are more rare and infrequent findings, but have been reported in some commercial rabbitries causing serious economic losses. Pyometra and metritis associated with Pasteurella multocida are more commonly seen, along with uterine adenocarcinoma, as the major uterine abnormalities in rabbits. Other bacterial agents reported infrequently to infect the uterus in rabbits include Chlamydia, Listeria monocytogenes, Moraxella bovis, Brucella melitensis, and Salmonella. In the staphylococcal outbreaks, metritis and abortions were reported, along with mastitis, ulcerative pododermatitis, interdigital abscesses, lung abscesses and pyothorax. Young rabbits showed no lesions prior to their death.

Staphylococcus aureus, a gram-positive, 1 µm, non-motile and non-spore- forming coccus, is the species most commonly isolated from affected rabbits and is also the most prevalent bacterial pathogen affecting humans. It can be spread by direct contact or by aerosol and can reside in the nasal sinuses or lungs without showing any apparent disease. Staphylococci produce many extracellular proteins that add to their pathogenicity: surface proteins that promote adherence, enzymes that degrade host compounds, and toxins that damage host cells. Staphylococci induce platelet aggregation, and S. aureus specifically produces coagulase, both properties which promote thrombosis of small vessels, as seen in the uterine submucosa of this rabbit. There is a high correlation between those Staphylococci that produce coagulase and those that produce toxins. Since the uterine infection was so acute and severe, it was likely that a staphylococcal toxin was also involved, most likely alpha-toxin which selectively damages the endothelial layer of blood vessels by forming hexameric pores within the plasma membrane.


Case 10-1. Uterus. Diffuse caseous necrosis of the endometrium with bacterial colonies on the surface and dense fibrin thrombi in the lamina propria. 20X

AFIP Diagnosis: Uterus: Endometritis, necrotizing, acute, diffuse, severe, with fibrin thrombi, edema, numerous cocci, and transmural lymphoplasmacytic, neutrophilic and histiocytic inflammation, rabbit, lagomorph.

Conference Note: A gram-stained section viewed in conference confirmed that the cocci are gram-positive. Participants also viewed additional histologic sections from this case, including sections of placenta and fetal lung. The placenta was diffusely necrotic, and there were numerous colonies of cocci within the placenta and mesometrium, and within several fetal bronchioles. The latter finding suggests that there was periparturient fetal distress, with aspiration of placental fluid.

In addition to coagulase and -toxin, other significant soluble factors produced by staphylococci include hyaluronidase, which depolymerizes hyaluronic acid of connective ground substances; staphylokinase, which activates serum proteases to induce fibrinolysis; and -toxin, which lyses erythrocytes.1

Contributor: Veterinary Resources Program, National Center for Research Resources, National Institutes of Health, Bethesda, MD 20892-5230

References:

1. Cheville NF (ed): Ultrastructural Pathology, Iowa State Univ Press, pp. 672-75, 1994.
2. Hollman A, Girvan G: Staphylococcosis in a commercial rabbitry. Vet Rec 119: 187, 1986.
3. Carolan MG: Staphylococcosis in rabbits. Vet Rec 119: 412, 1986.
4. Hobbs BA, Parker RF: Uterine torsion associated with either hydrometra or endometritis in two rabbits. Laboratory Animal Science, 40(5), pp. 535-6, 1990.
5. Johnson JH, Wolf AM: Ovarian abscesses and pyometra in a domestic rabbit. J Am Vet Med Assoc, 203(5), pp. 667-9, 1993.
6. Laher L, Thorin-Trescases N, Ding A, Laporte R, Osol G: Alpha-toxin perfusion: a new method for selective impairment of endothelial function in isolated vessels or intact vascular beds. Can. J. Physiol. Pharmacol. 73: 1669-73, 1995.
7. Percy DH, Barthold SW (eds): Pathology of Laboratory Rodents and Rabbits, Iowa State Univ Press, pp. 192-3, 1993.
8. Weisbroth SH, Flatt RE, Krauss AL (eds): The Biology of the Laboratory Rabbit, Academic Press, pp. 227-8, 1974.

International Veterinary Pathology Slide Bank:
Laser disc frame #8424, 8497, 13886



Case II - 4833-96 (AFIP 2592284)

Signalment: Adult, male, Cocker Spaniel dog.

History: The dog was treated for heartworms with Caparsolate® 4 days before death. He began vomiting after the last injection and vomited blood 2 days later. He became very lethargic and continued to vomit blood until death.

Gross Pathology: The stomach had red-black blotchy hyperemia on the serosa and mucosa with a moderate amount of dark red liquid, but no ingesta, in the lumen. Some dark red fluid was in the anterior intestine but the intestinal mucosa and serosa were not hyperemic. The kidneys had moderately pale, stippled cortices. The heart and lungs did not have any heartworms. Other organs were grossly normal.

Laboratory Results:

Parvovirus F.A. test -- negative
Lung culture -- no bacterial growth
Salmonella screen on intestine -- negative
Liver arsenic (wet weight) -- 3.1 ppm

Contributor's Diagnoses and Comments: Necrohemorrhagic gastritis, severe. Renal tubular necrosis, moderate. Renal tubular basement membrane mineral- ization, mild.

The arsenic level of 3.1 ppm was considered positive. Caparsolate® (sodium thiacetarsamide) is hepatotoxic and nephrotoxic and one side effect is vomiting, although the severe gastric lesions seen here are not specifically mentioned in the product information. Acute arsenic poisoning can cause severe hemorrhagic gastritis or gastroenteritis regardless of the route of exposure. The toxic range of arsenic is variable, but 7-10 ppm in the liver or kidney is considered probably toxic, and normal is less than 0.5 ppm. Arsenic is rapidly cleared from the body (half-life is 1.5 days) so the level was probably much higher when the Caparsolate® injections were being given.

The apparent false diagnosis of heartworm infection was not explained, but we occasionally get a dog for necropsy without heartworms that was positive by in-clinic occult heartworm immunoassay testing.

Case 10-2a. Kidney. Coagulation necrosis of cortical tubules, focal mineralized lumina debris, and tubular basement membrane mineralization. 20X
Case 10-2b. Stomach. Diffuse hemorrhage and necrosis throughout the mucosa. 10X
AFIP Diagnoses:
1. Stomach: Necrosis and hemorrhage, mucosal and submucosal, acute, diffuse, with multifocal neutrophilic gastritis, Cocker Spaniel, canine.
2. Kidney: Degeneration and necrosis, tubular, acute, diffuse, with medullary proteinaceous casts and mineralization of tubular epithelium and glomerular and tubular basement membranes.

Conference Note: Several conference participants observed an amphophilic to basophilic granular material, which they interpreted as mineral, within the gastric mucosa. Results of a Von Kossa stain performed at the AFIP were equivocal.

Participants considered a differential diagnosis for processes which might lead to the combination of lesions seen in this dog, specifically renal tubular and gastric necrosis; gastric hemorrhage; and mineralization of renal epithelial cells and basement membranes. Gastric necrosis and mineralization can be secondary to uremia, so causes of acute renal damage were also considered. The possibility that this dog had preexisting hepatic or renal disease cannot be excluded although significant chronic changes are not evident in the examined sections of kidney. According to the contributor (personal communication), autolysis of the liver hindered histologic evaluation of that organ, but hepatic necrosis was not observed. It is unknown whether or not this dog had hepatic and renal function tests prior to heartworm treatment. This dog lived in a small agricultural community, but there was no history of exposure to arsenic other than via the heartworm treatment, or to any other known toxins.

Contributor: Arkansas Livestock and Poultry Commission Laboratory, #1 Natural Resources Drive, Little Rock, AR 72205

References:

1. Hatch RC: Poisons causing abdominal distress or liver or kidney damage. In: Veterinary Pharmacology and Therapeutics, Booth NH, McDonald LE, eds., Iowa State Press, Ames, IA, 1988, pp. 1102-1107.
2. Kanzler K, managing editor: Veterinary Pharmaceuticals and Biologicals, 9th ed., Veterinary Medicine Publishing Co., Lenexa, Kansas, 1995/1996, pp. 619-620.
3. Duncan JR, Prasse KW, Mahaffey EA: Veterinary Laboratory Medicine: Clinical Pathology, 3rd ed., Iowa State University Press, Ames, IA, 1994, pp. 190-192.
4. Cotran RS, Kumar V, Robbins SL: Robbins Pathologic Basis of Disease, 5th ed., W.B. Saunders Company, 1994, pp. 980-981.

International Veterinary Pathology Slide Bank:
Laser disc frame #4739, 20585-87



Case III - B96-2171 (AFIP 2595763)

Signalment: 3-month-old, male, F344 rat.

History: This animal was given an experimental material orally 24 hours before sacrifice.

Gross Pathology: The liver was mottled and pale. There were no other gross findings.

Laboratory Results: AST: 26,760 (rat normal 75-118)
ALT: 15,360 (rat normal 29-65)

Contributor's Diagnosis and Comments: Moderate to severe, acute, multifocal to coalescing centrilobular hepatic necrosis.

Acute coagulative necrosis of the centrilobular region (Zone 3 of the liver acinus) is present throughout this section of rat liver. The necrosis of hepatocytes is most severe in zone 3, with complete dissolution of cytoplasmic components, karyorrhexis and karyolysis, and breakdown of sinusoidal endothelium with blood-filled "lakes" in the immediate vicinity of central veins. Phagocytosis by large cells assumed to be Kupffer cells is evident in the centrilobular region, and by Kupffer cells and intact hepatocytes at the periphery of the necrotic zones. Large numbers of neutrophils and lesser numbers of other mononuclear cells are abundant in or at the periphery of the necrotic zone (often approximating the Zone 2-3 boundary). Increased homogeneity of the hepatocytic cytoplasm with increased finely granular basophilia exists in the midzonal to centrilobular regions (Zone 1-2 of the liver acinus). Mitotic figures are rare throughout the section.

This case of acute hepatic necrosis occurred 24 hours following administration of coumarin (200 mg/kg). Coumarin and 3,4-dihydrocoumarin (a related derivative) have widespread use in perfumes, cosmetics, and other products as a fragrance enhancer. These chemicals were nominated by the Food and Drug Administration and the National Cancer Institute for carcinogenicity testing by the National Toxicology Program (NTP, 1993)

Coumarin toxicity in the liver is characteristic of the spectrum of lesions observed following acute high-dose administration of many hepatotoxicants. While no evidence of a regenerative response is yet apparent, cytoplasmic alterations evident in the midzonal region are highly suggestive of a chemical toxicity where the liver might respond with a subsequent regenerative wave of hepatocellular replication. These early cytoplasmic alterations are also consistent with studies illustrating the induction of microsomal enzymes by coumarin, an effect also characteristic of many hepatic toxicants and chemical carcinogens. Under chronic administration, coumarin has been shown to induce minor increases in renal tubular cell adenoma in male F344 rats, but did not induce hepatic tumors in male or female rats. In these two-year rat studies, the acute hepatocellular necrosis and cytoplasmic alterations observed at this dose have been shown to persist with continued exposure, and were shown to progress to bridging hepatic fibrosis with bile duct proliferation but not neoplasia.

The role of cell proliferation in the induction of chemical carcinogenesis has received considerable attention in toxicologic pathology. The hepatotoxicity demonstrated by coumarin in F344 rats is not an infrequent finding in industrial toxicology. Particularly, this form of "sustained" and "regenerative" cell proliferation has often been implicated in the hepatocarcinogenicity of tested ingredients. The case with coumarin in the rat illustrates, however, that continued marked hepatocellular damage and regenerative repair do not always result in a hepatocarcinogenic response.

Case 10-3. Liver. Centrilobular necrosis bridging to adjacent central vein regions.Periportal and mid-zonal hepatocytes are not affected. Note the portal triad (toward bottom). 10X
AFIP Diagnosis: Liver: Necrosis, centrilobular, bridging, diffuse, with neutrophilic inflammation, F344 rat, rodent.

Conference Note: Coumarin derivatives more familiar to conference participants are those which have been synthesized for use as anticoagulant rodenticides, such as warfarin, fumarin, pindone, diphacinone, brodifacoum, and bromadiolone. Moldy sweet clover poisoning of cattle was one of the first documented coagulopathies in animals. The sweet clover plant (Melilotus alba)contains coumarin, which is converted to dicumarol when the plant spoils in hay or silage. Ingestion of dicumarol or any of the above compounds results in the inhibition of vitamin K epoxide reductase, which causes the production of nonfunctional forms of the vitamin K-dependent coagulation factors II (prothrombin), VII (proconvertin), IX (Christmas factor), and X (Stuart-Prower factor). Factor VII has the shortest half-life, and thus is the first to be depleted, followed by factors IX and X. Prothrombin, with a half-life of about 40 hours, is the last to disappear. Depletion of these factors prolongs both the PT and the APTT, but does not interfere with platelet numbers or function, nor does it decrease fibrinogen concentration.

Contributor: The Proctor & Gamble Company, Miami Valley Laboratories, P.O. Box 398707, Cincinnati, Ohio 45239-8707

References:

1. National Toxicology Program Technical Report (NTP TR 422). 1993. Toxicology and carcinogenesis studies of coumarin (CAS No. 91-64-5) in F344/N rats and B6C3F1 mice. US Department of Health and Human Services, National Institutes of Health (NIH Publication No. 93-3153).
2. Valli VEO: The hematopoietic system. In: Pathology of Domestic Animals, 4th edition, Jubb KVF, Kennedy PC, Palmer N, eds., Academic Press, 1993, vol. 3, p. 264.
3. Duncan JR, Prasse KW, Mahaffey EA: Veterinary Laboratory Medicine: Clinical Pathology, 3rd ed., Iowa State University Press, Ames, IA, 1994, pp. 82-86.

International Veterinary Pathology Slide Bank:
Laser disc frame #16318



Case IV - Mü 2028/96 (AFIP 2600442)

Signalment: 16-year-old, female, lion (Panthera leo).

History: This animal was euthanized. The lesion was an incidental finding at necropsy.

Gross Pathology: Bilateral, multiple, thin-walled cysts, up to 2 cm in diameter, were visible in the ovarian parenchyma.

Contributor's Diagnosis and Comments: Cystic rete ovarii.

Multiple cysts of variable diameter (up to 2 cm) displacing the ovarian parenchyma are visible. The cyst lining varies from single to several layers of flattened to cuboidal epithelium. Some of the cysts are lined by cuboidal ciliated epithelium. Several cysts are filled with proteinaceous fluid. Occasionally folds which protrude into the cyst lumen and contain a blood vessel in the apical part can be observed.

In cats, as in other mammals, the rete ovarii consists of three parts: an intraovarian rete system, a connecting rete system, and an extraovarian system. The intraovarian rete is located in the ovarian medulla and is lined by cuboidal epithelium. At the tubular extremity of the ovary, the intraovarian system becomes a reticular formation of dilated tubules lined by ciliated columnar epithelium- the connecting rete. The extraovarian rete consists of tubules composed of ciliated columnar cells extending from the connecting rete and ending blindly in the periovarian tissue. Cysts of the rete system have been described in different species including cats. The epithelial lining of the cyst walls can vary from single to several layers of cuboidal or flattened to columnar and ciliated epithelial cells.

In this case the pathological findings in the ovaries were incidental findings at necropsy and did not result in any clinical abnormality. The animal was not part of a breeding program and therefore no attempts were made to breed her.

Case 10-4. Ovary. Multiple lined by very attenuated epithelium sometimes contain floccular eosinophilic material. A single ovarian follicle is in the collagenous stroma (center). 2X
AFIP Diagnosis: Ovary: Cystic rete ovarii, lion (Panthera leo), feline.

Conference Note: Cysts of the ovarian rete are only one of sixteen different types of cysts occurring in and around the ovary of domestic animals.3 The incidence and relative significance of these is variable among animal species. In the cow and sow, follicular cysts are most frequent, and are important causes of infertility. These occur less frequently in the bitch and queen. Cats with follicular cysts may show signs of hyperestrogenism. On the other hand, cystic rete ovarii are most common in the bitch and queen, and seldom if ever cause clinical signs.

Histologic differentiation of the various types of cysts can be difficult. Important features include the type(s) of epithelium lining the cyst, presence or absence of smooth muscle in the wall of the cyst, and anatomic location.

Contributor: Institute of Animal Pathology, Zoo Animal Pathology, University of Berne, Laenggassstrasse 122, CH 3012 Berne, Switzerland

References:

1. Gelberg HB, McEntee K, Heath EH: Feline cystic rete ovarii. Vet. Pathol. 21:304-307, 1984.
2. Wenzel JGW, Odend'hal S: The mammalian rete ovarii: a literature review. Cornell Vet: 75:411-425, 1985.
3. McEntee K: Reproductive Pathology of Domestic Mammals, Academic Press, Inc., 1990, pp. 52-68.

International Veterinary Pathology Slide Bank:
Laser disc frame #1019, 2704, 5145, 11889



Terrell W. Blanchard
Major, VC, USA
Registry of Veterinary Pathology*
Department of Veterinary Pathology
Armed Forces Institute of Pathology
(202)782-2615; DSN: 662-2615
Internet: blanchard@email.afip.osd.mil

* The American Veterinary Medical Association and the American College of Veterinary Pathologists are co-sponsors of the Registry of Veterinary Pathology. The C.L. Davis Foundation also provides substantial support for the Registry.
